Long-Endurance Drone Platform With Power-Line-Level Obstacle Sensing
Engineered for Excellence, Designed for Versatility
DJI Zenmuse H20N The Night Vision Payload Built for When Duty Calls After Dark. Available from aerosmart, Authorised DJI Dealer
Authorised DJI Dealer Genuine Product, Full Warranty
Starlight Cameras + Dual Thermal + Laser Rangefinder Five Sensors
Compatible With DJI Matrice 300 RTK
Delivery Across 14+ Countries With Export Documentation
The majority of emergency search and rescue operations take place at night. The most critical infrastructure inspection windows, when thermal gradients on electrical equipment are most pronounced and diagnostically useful, are at dawn and dusk. Anti-poaching patrols covering national park perimeters operate in complete darkness. The operational reality for Africa's public safety, emergency response, and inspection sectors is that the work does not stop when the sun goes down, and the equipment has to be ready for it.
The DJI Zenmuse H20N was designed specifically for nighttime operations. It integrates starlight-grade sensors into both its zoom and wide-angle cameras, delivering the stronger low-light performance that darkness demands. It pairs these with dual 640×512 thermal zoom cameras and a laser rangefinder to create a five-sensor hybrid payload that rises to every occasion presented by low-light and no-light operations. When thermal and visual intelligence work together through split-screen viewing, synchronised zoom, and simultaneous operation, the H20N does not just see in the dark. It delivers actionable operational intelligence in the dark.
aerosmart supplies and supports the DJI Zenmuse H20N as an authorised DJI dealer across 14+ African countries. Our team will ensure you receive the right configuration and complete support from day one.
Night vision, thermal imaging, zoom, rangefinder, and platform compatibility at a glance.
The H20N is not a night-mode addition to a standard daytime payload. It is a purpose-built night operations system where every sensor has been selected and configured specifically for the conditions that darkness creates and the operational requirements that night missions demand.
Night Vision Zoom Camera — Starlight Sensor, 4MP, 20× Optical Zoom, 128× Maximum Zoom
The H20N's zoom camera is built around a starlight-grade sensor, a sensor class designed to amplify the extremely low levels of ambient light available at night rather than relying on artificial illumination to function. At 20× optical zoom, extending to 128× maximum zoom, the starlight zoom camera identifies subjects and structural details at range in conditions where standard camera sensors produce dark, indistinguishable output.
4K video at 30 fps through the zoom camera maintains the image quality required for inspection documentation and evidence-grade surveillance across the entire zoom range. Night Scene Mode further improves low-light performance, making the H20N ideal for early-morning operations, late-evening operations, and other inspection periods when thermal gradients are most valuable for fault detection.
Starlight sensors work by capturing and amplifying the residual ambient light, including moonlight, starlight, and distant artificial light, that is present in nighttime environments. The result is clear and detailed imagery in extremely low-light conditions that would completely defeat standard CMOS sensors operating without active illumination.
For night surveillance operations where active lighting would compromise covert positioning, for search operations in remote areas without artificial light sources, and for the dawn-to-dusk inspection window covering periods of maximum thermal diagnostic value on electrical infrastructure, the starlight zoom camera delivers where standard cameras cannot.
At 128× maximum zoom, the H20N's zoom camera extends the aircraft's effective night identification range to the limits of what can be usefully observed from safe operational altitudes. Targets that would require dangerous proximity approaches when using standard cameras can be identified from a safer operational distance with the H20N's starlight zoom system.
Night Vision Wide Camera — Starlight Sensor, 2MP
The wide-angle starlight camera provides essential scene context throughout night operations. It creates the situational-awareness layer that prevents the narrow-field disorientation commonly produced during zoom-only night operations.
With a 2MP starlight sensor delivering stronger low-light performance than standard wide cameras, the H20N's wide view remains usable in conditions where conventional wide cameras cannot operate effectively. This gives the operator continuous spatial awareness of the full operational environment, even while the zoom camera focuses on specific subjects at range.
Dual Thermal Cameras — 640×512 Resolution, 2× and 8× Zoom
Two separate thermal cameras provide comprehensive thermal observation across different operating distances. The first offers 2× zoom with a 53 mm equivalent focal length for close- to medium-range thermal scene observation. The second provides 8× zoom with a 196 mm equivalent focal length for long-range thermal subject identification.
Together, the cameras deliver a combined thermal zoom capability of up to 32× when the 8× optical zoom is extended with digital magnification.
The dual thermal-camera architecture is the H20N's defining technical distinction from the H20T. Where the H20T carries a single thermal camera with one fixed thermal field of view, the H20N provides two distinct thermal observation distances.
The operator can switch between 2× and 8× thermal zoom or view both simultaneously in split-screen mode. This enables operators to manage both a wide thermal overview and the detailed thermal identification required for comprehensive night surveillance.
The 640×512 resolution on both thermal cameras delivers high-definition heat mapping and fine temperature-gradient discrimination. It enables operators to identify individual subjects, vehicles, and thermal anomalies across the operating ranges supported by the two zoom levels.
Human heat signatures can be detected through vegetation at range, vehicle-engine heat can remain visible immediately after shutdown, and electrical component temperature differentials can be identified from inspection altitudes. The dual thermal system supports the full range of nighttime operational thermal-intelligence requirements.
Laser Rangefinder — 3 m to 1,200 m, Night-Capable
The laser rangefinder operates continuously during night conditions, providing precise distance-to-target measurements from 3 metres up to 1,200 metres, regardless of ambient light levels.
During night search operations, the rangefinder helps generate precise location data for ground-team navigation. During night surveillance, accurate target-distance information supports tactical positioning decisions. During night inspections, distance measurements to thermal anomalies enable detailed and formal fault-location records.
The laser rangefinder delivers the critical spatial data that darkness removes from conventional visual measurement methods.
The H20N's synchronised zoom capability enables users to scale both the thermal and starlight night-vision camera images simultaneously, maintaining matched magnification between the thermal and visible channels as the operator zooms in or out. This doubles operational efficiency and makes it easier to compare details side by side. The thermal image and the starlight image remain aligned at the same zoom level, removing the constant manual readjustment required when independently controlled sensors are used.
What Synchronised Zoom Achieves in Night Operations
In a conventional dual-sensor operation without synchronised zoom, the operator manages two independent camera feeds. The operator must zoom in on the thermal image to identify a heat signature, separately zoom in on the visible image to confirm the subject visually, and then zoom back out on both feeds to restore situational awareness.
Each zoom adjustment requires a separate manual input, and every comparison requires the operator to re-establish visual correspondence between the two feeds. This coordination overhead slows the operational observation workflow.
With synchronised zoom, one input scales both images simultaneously. The thermal and starlight feeds remain matched in magnification and field of view throughout every zoom adjustment. The operator zooms in once and sees both the thermal signature and the starlight visible image of the same subject at the same scale, side by side and at the same time.
Confirmation is faster. Operational decisions are faster. A subject-identification workflow that would normally require multiple sequential steps with independent sensor control can be completed through a single zoom adjustment with the H20N.
Split-Screen Mode
Split-screen display presents the thermal and starlight camera feeds simultaneously in a divided-screen layout. The thermal image appears on one side and the starlight visible image appears on the other, with both displayed at the operator's selected zoom level.
The operator maintains continuous awareness of both sensing dimensions instead of repeatedly switching between them. The thermal camera provides the detection layer, while the starlight camera provides the identification and documentation layer. Both feeds remain visible simultaneously, eliminating the attention switching required by sequential view management.
For night search operations, the thermal feed can scan for heat signatures while the visible channel monitors the broader scene. For night surveillance, thermal tracking and visual documentation of the same subject can be performed simultaneously. For night inspections, thermal anomaly detection and visual structural documentation can both be captured as programme deliverables.
Split-screen mode provides the concurrent dual-channel visibility required for demanding night operations.
Most emergency situations do not schedule themselves for daylight hours. Public safety incidents, search activations, and disaster response scenarios occur at every hour. The aerial intelligence available to response teams at 2am can determine outcomes as directly as the capability available at 2pm.
Learn More ↗Africa's night operational requirements are specific and significant. Anti-poaching patrols across Kenya, South Africa, and Botswana operate primarily in darkness, when illegal activity is highest. Flood response, disaster recovery, and remote search operations also frequently take place in conditions where human visibility is near zero.
Learn More ↗The DJI Zenmuse H20N was designed specifically for these conditions. Its starlight sensors, dual thermal architecture, and synchronised zoom system make night operations highly effective rather than a degraded fallback that response teams must tolerate until sunrise.
Learn More ↗The DJI Zenmuse H20N carries an IP44 protection rating, sealing the payload against solid particles larger than 1 mm and water splashes from any direction. This keeps all five sensor systems operational through the damp and dewy conditions of critical pre-dawn inspection windows.
Learn More ↗Night environments are often wetter and more humid than daytime deployment conditions. Temperature drops after sunset can create condensation, dew, and surface moisture. The H20N's IP44 sealing helps maintain access to pre-dawn inspection and surveillance operations despite these challenging moisture conditions.
Learn More ↗The -20°C to 50°C operating temperature range covers Africa's varied night environments, from cold high-altitude operations in Ethiopia's Oromia highlands to warm, humid conditions across West Africa's coastal zones and the Nile basin.
Learn More ↗A single zoom input scales both thermal and starlight images simultaneously, maintaining matched magnification and field of view between the two sensor channels throughout every zoom adjustment. Operators can compare both feeds without making separate manual zoom inputs for each channel.
The H20N is the right choice when night operational effectiveness is the primary requirement. Its starlight sensors, dual thermal architecture, synchronised zoom, and split-screen viewing deliver stronger performance in darkness where standard CMOS cameras approach the limits of their low-light capability.
As an authorised DJI dealer, aerosmart provides genuine products, night operations configuration guidance, international delivery, technical support, training, and competitive enterprise pricing.
Every Zenmuse H20N carries original DJI warranty, current firmware certification, and regulatory-compliant documentation. No parallel imports. No counterfeit risk.
Our team advises on H20N versus H20T selection for your specific operational requirement and recommends the right Matrice 300 RTK configuration to support your night operations programme before purchase.
Direct shipping with full export documentation and import duty guidance for every destination market.
Dubai-based technical support for remote diagnostics, firmware updates, and hardware maintenance throughout the operational life of the payload.
H20N sensor operation, synchronised zoom, split-screen workflows, thermal calibration, and DJI Pilot 2 night operations configuration training are available remotely and in person.
Contact aerosmart for Zenmuse H20N pricing and complete Matrice 300 RTK + H20N night operations system quotes.
Every DJI Zenmuse H20N purchased through aerosmart comes with access to DJI Care Enterprise Plus, covering the payload from its activation date.
All DJI Care Enterprise Plus activations and warranty claims are handled directly by aerosmart, with no overseas routing and no third-party intermediaries.
Unlimited free repairs within the available coverage limit for the full duration of the plan.
Share the available coverage limit across your complete enterprise payload fleet.
Mail-in repairs include two-way shipping, with no hidden repair logistics costs.
Repairs are completed by DJI-certified engineers using genuine manufacturer-approved components.
An additional one-year warranty option is available for major payload components.
The DJI Zenmuse H20N is available from aerosmart, an authorised DJI dealer with delivery across 14+ countries. Contact our team for pricing, configuration advice, and availability.
The H20N is purpose-built for night operations. It integrates starlight-grade sensors into both its zoom and wide cameras and features dual thermal cameras with 2× and 8× zoom, synchronised zoom, and split-screen viewing. The H20T uses standard CMOS cameras with Night Scene Mode and a single radiometric thermal camera. The H20N is better suited to dedicated night operations, while the H20T is designed for thermal inspection and temperature measurement.
The H20N's starlight zoom camera delivers 20× optical zoom and up to 128× maximum zoom. Its dual thermal cameras provide separate 2× and 8× thermal zoom, combining for up to 32× total thermal zoom. Synchronised zoom scales the starlight and thermal images simultaneously using a single control.
The H20N integrates two separate 640×512 thermal cameras. One provides 2× zoom with a 53 mm equivalent focal length for wide thermal scene observation, while the second provides 8× zoom with a 196 mm equivalent focal length for long-range subject identification. Together, they support up to 32× total thermal zoom.
Synchronised zoom scales the H20N's thermal and starlight night-vision images simultaneously using a single zoom input. It maintains matched magnification and field of view between both sensor channels, removing the need for separate manual zoom adjustments and keeping the feeds aligned throughout night observation.
The DJI Zenmuse H20N is compatible with the DJI Matrice 300 RTK. aerosmart can advise on the complete Matrice 300 RTK and H20N night-operations system configuration before purchase.
The H20N laser rangefinder measures distances from 3 metres to 1,200 metres with an accuracy of ±(0.2 m + D × 0.15%). It supports precise GPS coordinate tagging of night detections, ground-team navigation, standoff-distance confirmation, and fault-location documentation.
DJI Zenmuse H20N pricing varies according to configuration and destination country. Contact aerosmart at africa@aerosmart.ae for an accurate quotation tailored to your night-operations requirement and aircraft configuration.
